System Manual Safety System CES-A-W5H-01
13
Safety switch CES-A-W5...
Voltage drop as a function of switching current and
cable length (examples)
Switching current Cable length "l" Voltage drop Max. voltage drop Max. voltage drop
[mA] [m] Output [V] Cable [V] Total [V]
6
(safety control system with
pulsed signals)
1 -100 1,4 0,1 1,5
101 - 300 1,4 0,4 1,8
50
(safety relay)
1 - 15 1,5 0, 1,7
16 - 50 1,5 0,5 ,0
51 - 100 1,5 1,0 ,5
101 - 300 1,5 3,0 3,5
400
(e. g. small contactor)
1 - 15 1,7 1, ,9
16 - 50 1,7 4,0 5,7
51 - 100 1,7 8,0 9,7
101 - 300 1,7 - -
