System Manual Safety System CES-A-W5H-01
15
Connection example
CES-A-W5H-01
Important!
To achieve category 4 according to EN ISO 13849-1, it is necessary to monitor
the downstream contactors (not shown here).
This example shows only an excerpt that is relevant for connection of the CES
system. The example illustrated here does not show complete system planning.
The user is responsible for safe integration in the overall system.
+24V DC
-F1
GND
Po
w
er
Su
pp
ly
Safety - PLC with static /
dynamic signals
O1 Pulsed output
O2 Pulsed output
I1 Input
I2 Input
A1
+LA
LA
+LB
LB -LAB 0V
+UB
OUT
Read head
6
3
8
4
EUCHNER
CES-A-W5H-01
097525
7 1
GND
+24V DC
-F2
2
5
