Operating Instructions Safety System CES-AZ-ALS-...
43
Actuator CES-A-BQA
Ì
Rectangular design 50 x 50 mm
Dimension drawing CES-A-BQA
Technical data
Parameter
Value
Unit
min. typ. max.
Housing material Fortron, reinforced thermoplastic, fully encapsulated
Dimensions 50 x 50 x 20.2 mm
Weight 0.07 kg
Ambient temperature -25 - +70 °C
Degree of protection IP67
Installation position Active face opposite read head
Power supply Inductive via read head
40 ±0,15
50 0,25
0
40
±0,
1
5
50
0,25 0
6
20,2
Ø
4,5
-
-
Active face
