Operating Instructions Safety System CES-AZ-ALS-...
31
Read head CES-A-LNA-SC
Ì
Rectangular design 42 x 25 mm
Ì
M8 plug connector (snap-action and screw terminals)
Dimension drawing
Typical operating distance
With evaluation unit CES-AZ-ALS-... and CES-A-BBA actuators
Note
For a side approach direction forthe actuator and read head, a minimum distance
of s = 3 mm must be maintained so that the operating distance of the side lobes
is not entered.
5,5
10
6,8
8
4,
5
4,6
12
25
min.38
32 ±0,1
42 32,6
A0
CES-A-L 077715
3
4
1
A0
CES-A-L 077715
20 1 ,
26,
5
2 safety screws M4 x 14
included
Cable outlet with
angled connector
Active face
Active face
X
20
15
10
5
20
15
10
5
5
10
15
20
Y
Z
