Operating Instructions Safety System CES-AZ-ALS-...
25
Read head CES-A-LNN-...
Ì
Rectangular design 42 x 25 mm
Ì
Attachment compatible with series CES-A-LNA/LCA
Ì
LED for the indication of the door position
Dimension drawing
Typical operating distance
With evaluation unit CES-AZ-ALS-... and actuator CES-A-BBN
Note
For a side approach direction for the actuator and read head, a minimum distance
of s = 6 mm must be maintained so that the operating distance of the side lobes
is not entered.
25
42
±0,
1
52,7
5,4
8
9
4,
1
5,3
12
4,5
4,
1 1
9,4
4,6
32
Active face
With M8 plug con-
nector
With connection cable
LED
Active face
Active face
Z
-25
-30
X
10
5
15
20
-20
-25
-30
-40
-35
-15
-10
-5
-10
20
25
30
15
10
40
35
5
Y
10
15
20
25
5
-5
-15
-20
30
