Operating Instructions Safety System CES-AZ-ALS-...
35
Read head CES-A-LQA-SC
Ì
Rectangular design 50 x 50 mm
Ì
M8 plug connector (snap-action and screw terminals)
Dimension drawing
Typical operating distance
40 ±0,15
50 0,25
0
M8
40
±0,
1
5
50
0,25 0
20
7
6
20,2
Ø
4,5
-
x1
-
Active face
10
-30
20
30
Z
Y
10
20
30
-30
30
20
10
X
With actuator CES-A-BBA or CES-A-BCA
10
20
30
Y
10
20
30
20
10
X
30
Z
With actuator CES-A-BQA on evaluation unit CES-AZ-...-01B
