Sheet2, Drawing view7, Drawing view8 – ERICO LENTON LOCK Closure Pour Splices User Manual
Page 2: Drawing view9, Instruction sheet
Step 5 Align rebar
Step 6 Center coupler, ensuring rebar marks (completed in step 2) line up correctly.
Step 7 Torque bolts per product instruction sheet PDF116 for B-Series
couplers or PDF121 for S-Series couplers.
TECHNICAL SUPPORT:
www.erico.com
PDF113_C
INSTRUCTION SHEET
2 of 2
