SES 200 Series
Transient Voltage Surge Suppression
 2000 ERICO

Inc, 34600 Solon Rd, Solon, OH 44139 Page 4 of 4 Doc: IPSES200.doc, Issue: A, Date: 9/13/2000
SES 200 SPECIFICATIONS
OPERATION:
Models available: SES200
120/240 120/208 277/480
Nominal line voltage 120/240Vrms 120/208Vrms 277/480Vrms
Distribution system 1PH 3W +G 3Ph 4W+G 3Ph 4W+G
Input frequency 50/60 Hz
PROTECTION*:
Surge material per line (8/20µs)
200/100kA
L-N 200/100kA
N-G 200/100kA
Protection modes L-N and N-G
SPD circuit description Parallel hybrid with TD technology
Short Circuit Interrupt Rating 200 kAIC
Surge Fuse Rating 100kA 8/20µs per line
ALARMS AND INDICATORS
Status indication
5-segment LED bar graph, alarm relay contacts
PHYSICAL DATA:
Dimensions (W x H x D)
Approx. 11” x 16” x 7” (280 x 406 x 180mm)
Weight Approx. 17 lbs.
Enclosure material Polycarbonate
Connection means #6 AWG wiring terminals
Environmental rating NEMA 4, 4X, 12, 13
Operating temperature +14 to +149°F (-10 to +65°C)
Humidity 0-90%
Altitude 0-12,000 ft (0-3650m)
Warranty 5 years
TEST STANDARDS:
Listing
cULus 1449 Edition 2
Surge rated to meet ANSI/IEEE C62.41-1991 Cat A, Cat B & Cat C
*Surge ratings are quoted “Aggregate MOV material/NEMA LS1 tested rating.”
Due to a policy of continual product development, specifications are subject to change without notice.
