ERICO CSBEZU - Sway Brace Fitting, Easy Universal Sway Brace - Manual (Page 2)

1. UL Listed for use with Lightwall Service Pipe, Schedule 10, and Schedule 40 Service Pipe, for use with 1 to 2 NPS Schedule 40 brace pipe or 1/4" angle iron.
*2. 2015 lbs. (8963 N) load rating when used with 1/4" angle iron.
**3. Rating with 1/4" angle iron is identical to Schedule 40 brace pipe.
UL® Loads (Listed for Restraints) - Lateral**
Part Number Dyna-Flow® Service Pipe Sch 10 Service Pipe Sch 40 Service Pipe
CSBEZU0100(XX) N/A 655 lb (2,914 N) 655 lb (2,914 N)
CSBEZU0125(XX) 655 lb (2,914 N) 655 lb (2,914 N) 655 lb (2,914 N)
CSBEZU0150(XX) 655 lb (2,914 N) 655 lb (2,914 N) 655 lb (2,914 N)
UL Loads (Listed for Sway Braces)
Part Number
Lateral* Longitudinal**
Dyna-Flow®
Service Pipe
EZ FLOW™
Service Pipe
Sch 10
Service Pipe
Sch 40
Service Pipe
Dyna-Flow®
Service Pipe
Mega-Flow
Service Pipe
Sch 10
Service Pipe
Sch 40
Service Pipe
CSBEZU0200XX
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A N/A N/A N/A
CSBEZU0250XX
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
1,265 lb
(5,627 N)
N/A
1,265 lb
(5,627 N)
1,265 lb
(5,627 N)
CSBEZU0300XX
3,000 lb
(13,345 N)
N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
1,265 lb
(5,627 N)
N/A
1,265 lb
(5,627 N)
1,265 lb
(5,627 N)
CSBEZU0400XX
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
1,265 lb
(5,627 N)
N/A
1,265 lb
(5,627 N)
1,265 lb
(5,627 N)
CSBEZU0500XX N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A
1,600 lb
(7,117 N)
1,600 lb
(7,117 N)
1,600 lb
(7,117 N)
CSBEZU0600XX N/A
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
3,000 lb
(13,345 N)
N/A
1,600 lb
(7,117 N)
1,600 lb
(7,117 N)
1,600 lb
(7,117 N)
TECHNICAL SUPPORT:
www.erico.com CFS386_H
INSTRUCTION SHEET
2 OF 17
© 2009, 2011, 2012, 2013, 2014 ERICO
International Corporation.
CADDY, CADWELD, CRITEC, ERICO, ERIFLEX, ERITECH, and LENTON are registered trademarks of ERICO International Corporation.
CSBEZU
Easy Universal Sway Brace or Restraint Device
Sway Brace Fitting
