Chapter 4: Installation
The Gold Trombone must be installed in a suitable environment and properly connected to its
voltage supplies and the motor.
4.1. Site Requirements
You can guarantee the safe operation of the Gold Trombone by ensuring that it is installed in
an appropriate environment.
Feature Value
Ambient operating temperature 0 °C to 40 °C (32 °F to 104 °F)
Maximum non-condensing humidity 90%
Maximum altitude 2,000 m (6562 feet)
Operating area atmosphere No flammable gases or vapors permitted in area
Models for extended environmental conditions are available.
Caution: The Gold Trombone dissipates its heat by convection. The maximum
ambient operating temperature of 40 °C (104 °F) must not be exceeded.
4.2. Unpacking the Drive Components
Before you begin working with the Gold Trombone, verify that you have all of its components,
as follows:
• The Gold Trombone servo drive
• The Elmo Application Studio (EAS) software and software manual
The Gold Trombone is shipped in a cardboard box with Styrofoam protection.
To unpack the Gold Trombone:
1. Carefully remove the servo drive from the box and the Styrofoam.
2. Check the drive to ensure that there is no visible damage to the instrument. If any damage
has occurred, report it immediately to the carrier that delivered your drive.
