rooT menu
When HART communication is established, the first menu displayed is the X
3302
Root menu:
1) Fire (Yes/no)
Indicates “Y” if the device is in a fire alarm status — analog output is at
20
mA,
fire alarm relay is actuated and LED is red.
2) Fault (Yes/no)
Indicates “Y” if a fault condition exists. Go to “Device Info” and select “Status
Info” to determine the nature of the fault.
3) device Info menu
Provides access to manufacturer and HART information, current device status,
factory settings, and history logs.
4) Command menu
This menu allows the operator to initiate a manual oi test and also to perform
various reset/clear functions.
5) device setup menu
This menu allows various setup, configuration and calibration functions.
devICe InFo menu
This menu allows access to a variety of “read only” information.
1) general Info menu
Factory information.
2) hArT Info menu
HART Specific Variables.
3) status Info menu
Current operating status and/or diagnostic information.
4) detector settings
Factory settings relating to relay operation, detector sensitivity and response.
5) history menu
Display log files: Alarm, Fault, General.
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
