2.3

95-8613

wrITe ProTeCT
This function enables the operator to enable/disable password and write protection capability, as well as to enter

or change a password. The device is provided from the factory with Write Protect off. With Write Protect on, the

use of a password is required to enable writing to the device.

1) set Password

The password is used to validate the command to enable or disable writes in the

device. (The factory default password is: 1*******. Once the password has been

changed, the default password is no longer valid.)

CaUtIon

Always record the new password. If the password is forgotten, the device
must be returned to the factory for re-programming.

2) set write Protect

With Write Protect “On”, variables cannot be written to the device and commands

that cause actions to be performed in the device cannot occur.

3) write protect (Y/n)

This indicates whether or not Write protect is enabled.

hArT seTuP
This menu allows editing of the following functions:

1) Poll addr

Address used by the host device to identify a field device.

2) Final Assembly no.

A number that is used for identification purposes, and is associated with the

overall field device.

3) Tag

Text that is associated with the field device installation. This text can be used by

the operator in any way.

4) date

Any date chosen by the operator to be used for any purpose.

5) descriptor

Text associated with the field device that can be used by the operator in any way.

6) message

Text associated with the field device that can be used by the operator in any way.

Write protect

1) Set Password

2) Set Write Protect

3) Write Protect (Y/N)

Device Setup Menu

1) Configuration Menu

2) Calibration Menu

3) Write protect

4) HART Setup

5) Real Time Clock

X3302 Root Menu

1) Fire (Yes/No)

2) Fault (Yes/No)

3) Device Info Menu

4) Command Menu

5) Device Setup Menu

HART Setup

1) Poll addr

2) Final Assembly No.

3) Tag

4) Date

5) Descriptor

6) Message
