Det-Tronics X3302 Multispectrum IR Flame Detector with HART User Manual
Page 10

8
2.3
95-8613
hArT Pv menu
1) Pv unit
Not implemented for X
3302
.
2) Pv
Not implemented for X
3302
.
3) Pv sensor unit
Not implemented for X
3302
.
4) Pv usL
Not implemented for X
3302
.
5) Pv LsL
Not implemented for X
3302
.
6) Pv minimum span
Not implemented for X
3302
.
7) Pv damp
Not implemented for X
3302
.
8) Pv Ao
Analog Output. The value that tracks the Digital Value representation, under
normal operating modes.
9) Pv Ao Alarm Type
Not implemented for X
3302
.
10) Pv % range
Percent of Range. The variable that tracks the Digital Value representation with
respect to the range defined by the Lower Range Value and Upper Range Value,
for normal operating modes. The units of this variable are always in percent.
11) Pv Xfer Function
Not implemented for X
3302
.
12) Pv range unit
Not implemented for X
3302
.
13) Pv urv
Not implemented for X
3302
.
14) Pv Lrv
Not implemented for X
3302
.
15) Pv snsr s/n
Not implemented for X
3302
.
HART PV Menu
1) PV Unit
2) PV
3) PV Sensor Unit
4) PV USL
5) PV LSL
6) PV Minimum Span
7) PV Damp
8) PV AO
9) PV AO Alarm Type
10) PV % Range
11) PV Xfer Function
12) PV Range Unit
13) PV URV
14) PV LRV
15) PV Snsr S/N
HART Info Menu
1) Universal rev
2) Fld dev rev
3) Final asmbly num
4) Tag
5) Date
6) Descriptor
7) Message
8) Num req preams
9) HART PV Menu
10) Condensed Status
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
