hArT CommAnd menu
The HART Command Menu allows the operator to perform diagnostic and service functions as follows:
1) self Test
Internal tests are performed and any detected problems are reported in “Status
Info”.
2) master reset
This function re-initializes the microprocessor, resets the operating software, and
initiates a hardware reset for both the sensor and the HART interface. Latched
relays are reset.
3) Loop Test
This test allows the operator to manually set the analog signal output (
4
to
20
mA)
to a fixed user defined value.
devICe seTuP menu
This menu allows various setup, configuration and calibration functions. When Write Protect is off, these menus
allow the operator to reconfigure or write new variables to the device.
1) Configuration menu
2) Calibration menu
3) write protect
4) hArT setup
5) real Time Clock
Refer to the appropriate sub-menus for details.
HART Command Menu
1) Self Test
2) Master Reset
3) Loop Test
Command Menu
1) Start Passive Oi
2) Start Active Oi
3) Clear Oi Fault
4) Reset Latches
5) Master Reset
6) Clear Data Log
7) HART Command Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Device Setup Menu
1) Configuration Menu
2) Calibration Menu
3) Write protect
4) HART Setup
5) Real Time Clock
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
