Det-Tronics X3302 Multispectrum IR Flame Detector with HART User Manual
Page 15
13
2.3
95-8613
deTeCTor seTTIngs
This menu shows factory settings relating to relay operation, detector sensitivity and response.
1) Fire relay L/nL
Fire relay contacts, latching (L) or non-latching (NL).
2) Fire relay ne/nde
Fire relay coil, normally energized (NE) or normally de-energized (NDE).
3) Fault relay L/nL
Fault relay contacts, latching (L) or non-latching (NL).
4) Fault relay ne/nde
Fault relay coil, normally energized (NE) or normally de-energized (NDE).
5) Aux relay L/nL
Auxiliary relay contacts, latching (L) or non-latching (NL).
6) Aux relay ne/nde
Auxiliary relay coil, normally energized (NE) or normally de-energized (NDE).
7) sensitivity
Detector sensitivity setting: Very high, High, Medium, or Low.
8) response Time
Fire alarm processing time in seconds.
hIsTorY menu
This menu provides historical information about the detector. Up to
32
events in each of the three categories will
be kept in non-volatile memory. When the log is full, the oldest event will be overwritten. The most recent event
will be displayed first.
1) Alarm Log
Scroll through
32
Alarm Logs with time, date and temperature stamp.
2) Fault Log
Scroll through
32
Fault Logs with time, date and temperature stamp.
3) general Log
Scroll through
32
General Logs with time, date and temperature stamp.
History Menu
1) Alarm Log
2) Fault Log
3) General Log
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Device Info Menu
1) General Info Menu
2) HART Info Menu
3) Status Info Menu
4) Detector Settings
5) History Menu
X3302 Root Menu
1) Fire (Yes/No)
2) Fault (Yes/No)
3) Device Info Menu
4) Command Menu
5) Device Setup Menu
Detector Settings
1) Fire Relay L/NL
2) Fire Relay NE/NDE
3) Fault Relay L/NL
4) Fault Relay NE/NDE
5) Aux Relay L/NL
6) Aux Relay NE/NDE
7) Sensitivity
8) Response Time
