13
STACKABLE LCC-LCD-LLC POWER CONNECTION
Ground Buss
Panduit to protect
line wire between
conduit and
disconnect switch.
Power connection at
Disconnect Switch
on equipment panel
behind front swing
panel
FRONT EQUIPMENT MOUNTING PANEL
DOOR LOCK
FRONT SWING PANEL
(CONTROL PANEL)
Conduit for power wires run from rear
to behind this panel
