12
LCC/LCD/LLC/LLD1-16-3 AND LCC/LCD/LLC/LLD1-51-3 EXHAUST
(ALL SERIES)
Exhaust located on left side of oven, towards the
rear.
Exhaust Stack Must Be Rated for These
Conditions:
SIZE: 1.88” x 2.88” (4.8 cm x 7.3 cm)
FLOW: LCC/LCD/LLC/LLD1-16-3 (all series) =
35 CFM (1 CLM)
FLOW: LCC/LCD/LLC/LLD1-51-3 (all series) =
73 CFM (2 CLM)
TEMPERATURE: LCC/LLC: 500 °F (260 °C)
TEMPERATURE: LCD/LLD: 662 °F (350 °C)
