37
APPENDIX C: INPUT RANGE CODES
The input ranges available (selectable via the front panel) are:
TYPE INPUT RANGE DISPLAYED
CODE
R 0 - 1650°C 1127
R 32 - 3002°F 1128
S 0 - 1649°C 1227
S 32 - 3000°F 1228
J 0.0 - 205.4°C 1415
J 32.0 - 401.7°F 1416
J 0 - 450°C 1417
J 32-842°F 1418
J 0 - 761°C 1419
J 32 - 1401 °F 1420*
T -200 - 262°C 1525
T -328 - 503°F 1526
T 0.0 - 260.6°C 1541
T 32.0 - 501.O°F 1542
K -200 - 760°C 6726
TYPE INPUT RANGE DISPLAYED
CODE
K -328 -1400ºF 6727
K -200 - 1373ºC 6709
K -328 - 2503ºF 6710
L 0.0-205.7ºC 1815
L 32.0-402.3ºF 1816
L 0-450ºC 1817
L 32.0-842ºF 1818
L 0-762ºC 1819
L 32-1404ºF 1820
B 212-3315ºF 1934
B 100-1824ºC 1938
N 0 - 1399ºC 5371
N 32 - 2550ºF 5324
* Factory default
For RTD Inputs
Note: Input conditioning jumper JU1 needs to be changed, see Appendix A. Also, the
Hardware Definition Code for the input type must be changed, see Appendix B.
INPUT RANGE DISPLAYED CODE
0 - 800°C 7220
32-1471°F 7221
32-572°F 2229
-101.0-100.0°C 2230
-149.8-212.0°F 2231
0-300°C 2251
INPUT RANGE DISPLAYED CODE
0.0-100.9°C 2295
32.0-213.6°F 2296
-200-206°C 2297
-328-403°F 2298
-101.0-537.3°C 7222
-149.8-999.1°F 7223
For DC Inputs
Note: Input conditioning jumper JU1 needs to be changed, see Appendix A. Also, the
Hardware Definition Code for the input type must be changed, see Appendix B.
INPUT RANGE DISPLAYED CODE
0-2OmA 3413
4-2OmA 3414
0-5OmV 4443
10-5OmV 4499
INPUT RANGE DISPLAYED CODE
0-5V 4445
1-5V 4434
0-10V 4446
2-10V 4450
