COATS 50xx Series Tire Changer User Manual
Tire changer
1601 J. P. Hennessy Drive, LaVergne, TN USA 37086-3565 615/641-7533 800/688-6359
Manual Part No.: 8182883 04
HENNESSY INDUSTRIES INC. Manufacturer of AMMCO
®
, COATS
®
and BADA
®
Automotive Service Equipment and Tools.
Revision:
07/09
Safety Instructions
Operating Instructions
Maintenance Instructions
Installation Instructions
®
* 5050, 5060 & 5065 Models Shown
5050/5060/5065 AX/EX
5040 A/E
Rim Clamp
®
Tire Changer
For servicing single piece automotive and most light truck
tire/wheel assemblies
READ these instructions before placing unit in
service. KEEP these and other materials delivered
with the unit in a binder near the machine for
ease of reference by supervisors and operators.
See
RIM Safety back cover
Operating
Instructions
page 3
