COATS 4070 Tire Changer - Manual (Page 5)

Important: Always read and follow operating instructions. • 1
Read entire manual before assembling,
installing, operating, or servicing this
equipment.
NOTICE
Table of Contents
Tire Specifications Diagram ..................................... ii
Safety Instructions .................................................. iii
Owner’s Responsibility ............................................iii
Operator Protective Equipment ...............................iii
Definitions of H azard Levels ....................................iii
Safety Notices and Decals ......................................iv
Remember R.I.M. ....................................................iv
Principle Operating Parts ......................................... 2
Know Your Unit ........................................................ 2
Operating Instructions ....................................... 3 -11
Tire Bead Loosening and Demounting ............... 3 - 5
Tire Mounting ..................................................... 6 - 7
Inflation..............................................................7 - 11
Stages of Inflation on a Conventional Tire
and Rim ................................................................... 12
Mismatched Tires and Wheels ............................... 13
Performance Tires/Custom Wheels ................ 14 - 15
Custom and Special Wheels .................................. 15
Tube Type Tires ........................................................ 16
Maintenance Instructions ............................... 16 - 18
Cylinder Maintenance ............................................ 16
Filling 8" Cylinders ................................................. 16
Pressure Gauge Maintenance
and Calibration ........................................................17
Lower Shoe Setting ................................................17
Routine Maintenance ............................................ 18
Setup Instructions .................................................. 18
Location ................................................................. 18
Air Source .............................................................. 18
Floor Mounting ...................................................... 18
Critical Safety Instructions ...................... Back Cover
