COATS Speed-Mag Adapter Set User Manual
Operating instructions with parts identification
1601 J. P. Hennessy Drive, LaVergne, TN USA 37086-3565 615/641-7533 800/688-6359
Manual Part No.: 8107758 01
HENNESSY INDUSTRIES INC. Manufacturer of AMMCO
®
, COATS
®
and BADA
®
Automotive Service Equipment and Tools.
Revision:
07/02
Speed-Mag Adapter
Set for Center Post
Tire Changers
®
Operating Instructions
with Parts Identification
READ these instructions before placing unit in
service KEEP these and other materials delivered
with the unit in a binder near the machine for
ease of reference by supervisors and operators.
