COATS CDH-9043 Electric-Hydraulic Tire Changer User Manual
Page 7

7
8
LAYOUT OF FUNCTIONAL PARTS
WARNING!
During all operations, keep hands and other parts of the body as far
as possible from moving parts of the machine. Necklaces, bracelets
and too large clothes, can be dangerous for the operator.
B/6
B/7
1
5
1 - Lifting bracket
2 - Self-centering chuck holding arm
3 - Self-centering chuck
4 - Sliding ramp
8 - Handler
9 - Switch
10 - Pedal
11 - Handler
13 - Carriage
14 - Tool holding arm
15 - Arm lever
17 - Bead breaking disk
18 - Tool
22 - Jaw
A
1
C
