2 • Important: Always read and follow instructions.
Specifi cations
Wheel Diameter Range
8 - 30 inches (203 - 762 mm)
Wheel Width Range
2 - 20 inches (51 - 508 mm)
Maximum Outside Tire Diameter
Up to 44 inches (1118 mm)
Maximum Tire/Wheel Weight
160 pounds (73 Kg)
Mounting Shaft Diameter
40 mm
Resolution (Round Off Mode)
0.25 ounce, position 1.40 degrees
Resolution (Fine Mode)
0.01 ounce, position 1.40 degrees
Balancing Display Increments
0.25 or 0.01 ounces
Electrical Requirements
230V, 1 PH, 60 Hz, 20A
NEMA L6-20R
230V, 3 PH, 60 Hz, 20A
NEMA L15-20R
(use grounding type plug)
Footprint
Width: 60 inches (1524 mm)
Depth: 60 inches (1524 mm)
Height: 78 inches (1981 mm)
Shipping Weight
650 pounds (295 Kg)
(without accessories)
Features
• Direct Drive System
• ProBalance™ Technology
• Direct Select™ Weight Placement
• Behind the Spoke Weight Placement
• Automatic Start When Hood Is Lowered
• Automatic Data Entry for Offset, Diameter & Width
- Manual Entry Backup on all Parameters
• Simple, Interactive User Interface - Touchscreen
• Operator Memory for Two Different Users
• Static, Dynamic And Multiple Tape-A-Weight
®
• Laser Guided Operation™ System
• Auto Wheel Positioning
• Hood Safety Interlock System
• MET Lab Listing
Accessory Options
Basic Pro Extended Pro Premium Pro
Description Part Number 85609487 85609488 85609489
Stub Shaft 8500920401 x x x
Bracket/Peg Accessory 8111054 x x x
Weight Tray Stud
(6 included) 85608850 x x x
8 Double Sided Collets 85609499 x x x
Calipers 8309011 x x x
Premium Wheel Weight
Hammer 8113175 x x x
Premium Quicknut 85607503 x x x
Small Pressure Cup &
Rubber Lip 8112106 x x x
No Mar Ring 85608312 x x x
Spring 8112107 x x x
Scraper 8113390 x x x
Short Cone 8112421 x x
Light Cone Kit
(4.8” - 6.8”) 8113277C x x
Faceplate Extension 8111935 x x
Pin-Plate System with
Balancer Mate 8KPPBM40 x
