COATS Kit 8111864 Motorcycle Wheel Adapter User Manual
Page 4
Parts Listing
ITEM
PART NO.
QTY
DESCRIPTION
1
111779
1
Jaw Connector
2
111778
4
Spring
3
111777
4
Screw, M8x25
4
111776
4
Lock Nut
5
111775
2
Screw, M6x70
6
111774
2
Stopper
7
111773
2
Lock Jaw
8
111780
2
Screw, TSEI, M8x25
9
111781
1
Key, Hexagonal, 15mm
10
111782
1
Long Hub, 28.5
11
111863
2
Screw, VTCEI, M6x18
12
111783
1
Wheel Holding Shaft
13
111784
2
Centering Cone
14
111785
1
Bushing, 17x14mm
15
111786
2
Spacer
16
111781
1
Collet for Shaft
17
111789
2
Bushing - BMW Wheels
18
111790
1
Bushing, 20x14mm
19
111791
1
Bushing, 25x14mm
20
111792
2
Cone - BMW Wheels
111865 11/97
©COPYRIGHT 1997 HENNESSY INDUSTRIES AND COATS ALL RIGHTS RESERVED PRINTED IN U.S.A.
