Figure 5 – Wheel Installed, Before Jaw Contact
Figure 6 – Jaws in Contact with Wheel
Use caution to avoid
personal injury. The
springs pulling the
lock jaws towards the wheel are very stiff.
Balancing Motorcycle Wheels
IMPORTANT: If the balancer being used does not
have a hood, use caution when balancing the
wheel. Always wear eye protection and keep
bystanders away. Do not attempt to stop the
wheel manually. Wait for the balancer to brake
the wheel to a complete stop before contacting
the wheel.
REMEMBER: This instruction sheet is intended to
supplement your COATS Wheel Balancer
Operating Instructions manual. It does not
replace the manual. Read and understand the
entire manual before attempting to use the
balancer.
1. Turn the balancer on and select STATIC mode
balancing. Remove any weights on the wheel.
NOTE: In STATIC mode, the wheel width and
offset values are not used by the balancer’s
computer. However, a value must be entered
for these parameters so that the balancer will
operate properly. Steps 3 and 4 will direct you
to manually enter the measurements.
2. Press the diameter key and enter the wheel
diameter. For example, press 1 then 8 then 0
to enter a wheel diameter of 18 inches.
3. Press the offset key, then press 6 and then 0.
You have entered an offset of 6.0.
4. Press the wheel width key, then press 6 and
then 0. You have entered a wheel width of 6.0.
5. Press START. Wait for the wheel to spin and
brake to a complete stop. Readings will
appear in the display.
6. Rotate the wheel until the left weight position
lights flash.
7. Attach the specified weight at top-dead-center
by one of the following methods:
Wire Spokes: Clip the weight onto the spoke
nearest to top-dead-center, or use 2 weights
that are 1/2 the specified amount, and place
them on the 2 spokes on either side of top-
dead-center. An adhesive weight can be used
if placed directly on the middle of the rim.
Cast or Composite Wheels: If the wheel has a
center rib and factory clip weights (Honda, for
example), attach the weight over the rib. If the
wheel has a center rib and adhesive weights
are being used, divide the weight in half and
place on either side of the rib. An alternate
method is to bend the weight in half over the
center rib.
8. Press START. The display should now read
0.00 (in non-round-off mode).
9. Remove the wheel. If you are balancing
another wheel identical to this one, you do
not need to remeasure the wheel or reset the
measurements. Simply mount the next
wheel, remove any weights, and press START.
CAUTION
!
