chiliGREEN P170HM - Manual (Page 41)

Specifications - 35
Concise User’s Guide
English
Specifications

Latest Specification Information
The specifications listed in this sec-
tion are correct at the time of going to
press. Certain items (particularly pro-
cessor types/speeds) may be
changed, delayed or updated due to
the manufacturer's release schedule.
Check with your service center for de-
tails.
RAM Module Speeds
Use either 1066MHz, 1333MHz OR
1600MHz DDRIII (DDR3) modules of
the same brand. Do not mix DRAM
speeds/brands in order to prevent un-
expected system behavior.
RAID Hard Disks
All hard disks in a RAID should be
identical (the same size and brand)
in order to prevent unexpected sys-
tem behavior.
Processor Options
Models A, C & D:
Intel® Core™ i7 Processor Extreme Edition
i7-2920XM (2.50GHz)
8MB L3 Cache, 32nm, DDR3-1600MHz, TDP
55W
Intel® Core™ i7 Processor
i7-2820QM (2.30GHz)
8MB L3 Cache, 32nm, DDR3-1600MHz, TDP
45W
i7-2720QM (2.20GHz) , i7-2630QM (2.0GHz)
6MB L3 Cache, 32nm, DDR3-1600MHz, TDP
45W
i7-2520M (2.50GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz, TDP
35W
Model B:
Intel® Core™ i7 Processor
i7-2820QM (2.30GHz)
8MB L3 Cache, 32nm, DDR3-1600MHz, TDP
45W
i7-2720QM (2.20GHz) , i7-2630QM (2.0GHz)
6MB L3 Cache, 32nm, DDR3-1600MHz, TDP
45W
i7-2520M (2.70GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz, TDP
35W
Intel® Core™ i5 Processor
i5-2410M (2.30GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz, TDP
35W
Intel® Core™ i3 Processor
i3-2310M (2.10GHz)
3MB L3 Cache, 32nm, DDR3-1333MHz, TDP
35W
Memory
*Four 204 Pin SO-DIMM Sockets Support-
ing DDR3 1333/1600** MHz Memory Mod-
ules
Memory Expandable up to 16GB
Compatible with 2GB or 4GB Modules
*Note: Four SO-DIMMs are only supported by
Quad-Core CPUs; Dual-Core CPUs support
two SO-DIMMs maximum
**Note: 1600 MHz Memory Modules are only
supported by Quad-Core CPUs to a maximum
of two SO-DIMMs
BIOS
AMI BIOS (32Mb SPI Flash-ROM)
