Concise User’s Guide
3.75G/HSPA Module (Option) - 31
Engl
ish
3.75G/HSPA Module (Option)
(Optional for Models A & B Only)
If you have included an optional 3.75G/HSPA module in
your purchase option, follow the instructions below to in-
stall the USIM card (which will be provided by your ser-
vice provider), and then run the appropriate application
supplied with your module.
USIM Card Insertion
1. Turn off the computer, and turn it over and remove the bat-
tery
(slide the latches in the direction indicated below and
slide the battery out).
2. Insert the USIM card as illustrated below until it clicks into
position, and replace the battery.
Wireless Manager
With the 3.75G/HSPA module and USIM card (supplied
by your service provider) installed you may then install
the
Wireless Manager application . The Wireless
Manager application allows you to directly access your
internet service from the computer.
Wireless Manager Installation
1. Make sure you enable power to the module by pressing
the Fn + key combination (the on-screen visual
indicator will indicate the module’s power sta-
tus).
Note: If a Found New Hardware window appears,
click Cancel in all windows that appear, and then pro-
ceed to install the driver as below.
2. Click Option Drivers (button).
3. Click 5.Install 3G Driver > Yes.
4. Click Next > Next > Install.
5. Click Finish.
6. Access the Wireless Manager application from the
Start menu or the desktop shortcut .
1
Fi 20
Figure 20 - Remove the battery
& Insert the USIM Card
