113
~
6-1/2"
~12-9/32"
Scale 1/1
W
all Mount Bracket
Template
P/N 115074
For
Model DH5000
Direct V
ent Option
and
Condensate Removal Option
Electrical
Control Box
Top W
all Mount Bracket
Bottom W
all Mount Bracket
1/4" Hole
1/4" Hole
1/4" Hole
1/4" Hole
See Reverse Side for Installation Instructions
Form No. 115074 012712
Kit P/N 900958 Control Box Wall Mount Kit
