Sensor Reset
Cau on! Performing the following procedure will reset all Network se ngs,
including disabling the DHCP. A crossover Ethernet cable will be required to
access the LOE’s internal webpage and re-enable the DHCP.
Disconnected the sensor from power. Press and hold down the reset bu on
while reapplying power. Con nue to hold the bu on for another 10 seconds
a er applying power. The LOE is now reset to default parameter values. In
order to access the internal webpage, follow the instruc ons below:
Computer Setup:
1. Click Start, Control Panel, and then open the Network Connec ons.
2. Right click on the Local Area Connec on and click Prope es.
3. In the center box scroll down and select Internet Protocol (TCP/IP) and then
click the Proper es bu on.
4. Select Use the following IP address and enter in the following:
IP Address: 169.254.0.201
Subnet Mask: 255.255.255.0
NOTE: if “Use the following IP address” is already checked and network
parameters have been assigned, contact your network administrator for
assistance.
LOE Setup:
5. Connect the sensor to a computer’s Ethernet port using a crossover Ethernet
cable.
NOTE: if a POE-injector is being used, the crossover cable will be between
the computer and the injector’s LAN port. Use a standard Ethernet cable
between the injector’s LAN+DC port and the LOE.
6. Apply power to the LOE. The sensor should start cking and the COM LED
should fl ash approximately every 30 seconds.
