3 = Standing Cylindrical Tank with Conical Bo om
Enter all dimensions shown below into the Tank Parameter fi elds and select the
desired Volume Units.
4 = Standing Rectangular Tank with Chute
Enter all dimensions shown below into the Tank Parameter fi elds and select the
desired Volume Units.
Tank X
Chute
Length
Tank Y
Empty
Distance
Full
Distance
or
Chute Y
Chute X
Diameter
Full
Distance
Empty
Distance
Cone
Length
Cone
Diameter
