Trip Point Relay Control (con nued)
Type 4 (Inclusive): ac vates when the target is within the trip window. This
can be used for various presence detec on applica on.
Type 5 (Hysteresis Far): When the target moves beyond the Trip Distance
+ Trip Window, the relay will ac vate and remain on un l the target moves
closer than the Trip Distance. The relay will then deac vate and remain off
un l the target once again moves beyond the Trip Distance + Trip Window.
Used for fi lling control or low alarm with hysteresis to prevent cha er.
Type 6: Disables the trip point relay.
Type 7 (Loss of Echo): the relay will ac vate if the sensor enters a loss of
echo condi on (no targets detected).
Type 8 (Timed Relay): sets the relay to ac vate at a specifi ed interval. The
Trip Distance parameter sets the me interval between relay ac va ons (in
minutes), and the Trip Window determine how long the relay remains ac ve
at each interval (in seconds).
Type 9 (Rate of Change): allows the user to defi ne a maximum rate of
change (distance over me), which if exceeded will ac vate the relay. The
Trip Distance parameter is used to defi ne the me value, and the Trip
Window parameter is used to defi ne the distance value.
Retry Time
Sets the delay between a empts to connect to the Website a er a failed
connec on. The Retry Time is also used to set the delay before repor ng trip
alarms to the website. Refer to Alarm Filter .
