2N Helios IP Verso
®
Basic Unit
Outputs
out1 - digital output
relay1 - relay output
Inputs
in1 – digital input on basic unit
I/0 Module
T h e i n p u t s / o u t p u t s a r e a d d r e s s e d a s f o l l o w s :
, e.g. module5.relay1. .
The module name is configured in the Hardware / Module name parameter in the
Extenders menu.
Outputs
relay1 - 1 relay output
relay2 - 2 relay output
Inputs
in1 – 1 digital input
in2 – 2 digital input
tamper – tamper switch (if installed)
Wiegand Module
The input is addressed as follows: ., e.g.
module2.tamper
The module name is configured in the Module name parameter in the Hardware /
. Extenders menu
Inputs
tamper – tamper switch (if installed)
