2N Helios IP Force/Safety
®
Outputs
relay1 – relay output on basic unit
output1 – active digital output on basic unit (for board version 555v3 and
higher, active digital output is connected with relay output 1 in 555v2 boards)
relay2 – relay output on additional switch (if installed)
output2 – active digital output on additional switch (if installed)
cr_relay1 – relay output on card reader (if installed)
cr_output1 – active digital output on card reader (if installed)
led_secured – red LED indicator on card reader (if installed)
led_ringing – orange LED indicator of ringing (for
) models with pictograms only
led_connected – blue LED indicator of connected call (for models with
) pictograms only
led_door – green LED indicator of door opening (for models with pictograms
only)
led_key1 – first button backlight at Safety
led_key2 – second button backlight at Safety
led_key3 – third button backlight at Safety
Inputs
tamper – tamper switch (if installed)
cr_input1 – digit input 1 on card reader (if installed)
cr_input2 – digital input 2 on card reader (if installed)
2N Helios IP Audio/Video Kit
®
Outputs
relay1 – relay output
output1 – digital output 1
output2 – digital output 2
led1 – LED 1 control output
led2 – LED 2 control output
led3 – LED 3 control output
Inputs
input1 – digital input 1
input2 – digital input 2
