Section 3 - Controls and Indicators
3-22
31200150
3.3
STEER MODES
Three steer modes are available for operator use.
Note: 2-Wheel Front Steer mode is required for travel on public roads.
Steer Mode Change
1. Bring machine to a stop using service brake while either circle steer mode (1) or
crab steer mode (3) is selected.
2. Turn the steering wheel until the left rear wheel (4) is aligned with the side of the
machine.
3. Select front steer mode (2).
4. Turn the steering wheel until the left front wheel (5) is aligned with the side of
the machine.
5. Wheels are now aligned. Select desired steer mode.
OAL2030
2-Wheel Front Steer
4-Wheel Circle Steer
4-Wheel Crab Steer
OAL2790
1
2
3
R
N
F
BEFORE S/N 0160040675 EXCLUDING 0160040468 & 0160040672
S/N 0160040675 & AFTER INCLUDING 0160040468 & 0160040672
OAM2400
4
5
