Section 5 - Attachments
5-31 31200150
Right Hand Hydraulic Joystick
• Move joystick left to (side) tilt left.
• Move joystick right to (side) tilt right.
To Raise/Lower Mast:
Press Forks Raise/Lower Switch (6) located on dash panel to activate Forks Raise/
Lower function.
The auxiliary hydraulic joystick controls the mast raise/lower function.
Left Hand Hydraulic Joystick
• Move joystick up to lower.
• Move joystick down to raise.
Right Hand Hydraulic Joystick
• Move joystick left to lower.
• Move joystick right to raise.
Installation Procedure:
• Refer to “Attachment Installation” on page 5-13.
Operation:
• Always lower forks fully in mast before engaging load.
• To drive with a load, lower forks fully in mast and travel in accordance with the
requirements set forth in Section 1 - General Safety Practices.
• Use a signal person to assist in positioning load if necessary.
Equipment Damage Precautions:
• Do not use forks as a lever to pry material. Excessive prying forces could
damage forks or machine structure.
• Do not attempt to lift loads that are attached or connected to another object.
WARNING
CRUSH HAZARD. Do not use mast to push or pull objects or load. Failure to
comply could cause object or load to fall.
WARNING
CRUSH HAZARD. Do not use side tilt to push or pull objects or load. Failure to
comply could cause object or load to fall.
