SECTION 6 - JLG CONTROL SYSTEM
6-40 – JLG Lift – 3121142
HI TILTED - NO/YES Displays status of hi tilt input. (Displayed if external tilt sensor is configured)
AUX POWER OP/CL Displays the status of the auxiliary power switch input
HORN OP/CL Displays the status of the horn input
R FILTER OP/CL Displays the status of the return hydraulic filter by-pass switch. Displayed
ONLY if MODEL = 600 (Configuration digit = 3)
C FILTER OP/CL Displays measured status of charge pump filter bypass switch. Displayed ONLY
if MODEL = 600 (Configuration digit = 3)
JIB BLOCK OP/CL Displays jib block limit switch status. Not displayed if associated configuration
digit = 0
BASKET STOWD YES/NO Displays status of basket stowed mode. (Displayed if MODEL NUMBER = 7 or 8)
SOFT LIMIT OP/CL Displays status of soft touch limit switch. Not displayed if associated configu-
ration digit = 0
SOFT O/R OP/CL Displays status of soft touch override switch. Not displayed if associated con-
figuration digit = 0
GEN SET/WELDER OP/CL Displays generator/welder switch input status. Not displayed if associated
configuration digit = 0
LIGHTS OP/CL Displays head and tail light switch input status. Not displayed if associated
configuration digit = 0
BSK TILT1 XX.X Displays indicated platform tilt angle. Displayed on models equipped with
Electronic Platform Leveling.
BSK TILT2 XX.X Displays indicated platform tilt angle. Displayed on models equipped with
Electronic Platform Leveling.
AXLE RET SW OP/CL Displays status of axle extension user switches. (Displayed if MODEL NUMBER
= 7 or 8)
AXLE EXT SW OP/CL Displays status of axle retraction user switches. (Displayed if MODEL NUMBER
= 7 or 8)
AXLE LIM SW RET/EXT Displays status of axle extension limit switches. (Displayed if MODEL NUMBER
= 7 or 8)
DOS LIM SW OP/CL Displays status of Drive Orientation System Limit Switch. (Displayed if MODEL
NUMBER = 7 or 8)
DOS O/R SW OP/CL Displays status of Drive Orientation System Override switch. (Displayed if
MODEL NUMBER = 7 or 8)
CAPACITY SW 500/1000 Displays status of capacity selection switch. (Displayed if MODEL NUMBER = 7
or 8)
Table 6-5. Machine Diagnostics Parameters
Diagnostics Submenu
(Displayed on Analyzer
1
st
Line)
Parameter (Displayed on
Analyzer 2
nd
Line)
Parameter Value
(Displayed on Analyzer 2
nd
Line)
Description
