SECTION 6 - JLG CONTROL SYSTEM
6-24
– JLG Lift –
3121142
SWING:
ACCEL X.Xs
Displays/adjusts swing acceleration
0.1 to 5.0 sec
2.0
2.0
DECEL X.Xs
Displays/adjusts swing deceleration
0.1 to 3.0 sec
1.5
1.5
MIN LEFT XX%
Displays/adjusts minimum swing left speed
0 to 50%
40
40
MAX LEFT XXX%
Displays/adjusts maximum swing left speed
0 to 100%
65
65
115-125
115-125
MIN RIGHT XX%
Displays/adjusts minimum swing right speed
0 to 50%
40
40
MAX RIGHT XXX%
Displays/adjusts maximum swing right speed
0 to 100%
65
65
115-125
115-125
CREEP LEFT XX%
Displays/adjusts maximum swing left speed
NOTE: used when creep switch on pump pot is
active
0 to 65%
50
50
CREEP RIGHT XX%
Displays/adjusts maximum swing right speed
NOTE: used when creep switch on pump pot is
active
0 to 65%
50
50
MAIN TELESCOPE:
ACCEL X.Xs
Displays/adjusts main telescope acceleration
0.1 to 5.0 sec
1.5
1.5
DECEL X.Xs
Displays/adjusts main telescope deceleration
0.1 to 3.0 sec
1.0
1.0
MIN IN XX%
Displays/adjusts minimum main telescope in
speed. Same as Creep speed
0 to 65%
15
15
MAX IN XXX%
Displays/adjusts maximum main telescope in
speed
0 to 100%
65
65
58-68
65-75
MIN OUT XX%
Displays/adjusts minimum main telescope out
speed. Same as Creep speed
0 to 65%
15
15
MAX OUT XXX%
Displays/adjusts maximum main telescope out
speed
0 to 100%
60
60
45-55
50-60
BASKET LEVEL:
ACCEL X.Xs
Displays/adjusts basket level acceleration
0.1 to 5.0 sec
1.5
1.5
DECEL X.Xs
Displays/adjusts basket level deceleration
0.1 to 3.0 sec
0.5
0.5
MIN UP XX%
Displays/adjusts minimum basket level up
speed. Same as Creep speed
0 to 65%
40
40
MAX UP XXX%
Displays/adjusts maximum basket level up
speed
0 to 100%
70
70
MIN DOWN XX%
Displays/adjusts minimum basket level down
speed. Same as Creep speed
0 to 65%
40
40
MAX DOWN XXX%
Displays/adjusts maximum basket level down
speed
0 to 100%
70
70
Table 6-3. Personality Ranges/Defaults
SUBMENU
(DISPLAYED ON
ANALYZER 1ST LINE)
PARAMETER
(DISPLAYED ON ANALYZER 2
ND
LINE)
DESCRIPTION
RANGE
DEFAULT VALUES
TIME RANGE (SEC) (SEE
SECTION 6.10 FOR
MACHINE ORIENTATION
WHEN SETTING SPEEDS)
1200
1350
1200S
1350S
