SECTION 2 - TURNTABLE
3121208 1200SJP/1350SJP 71
FIGURE 2-3. TURNTABLE SWING DRIVE AND BEARING INSTALLATION
ITEM PART NUMBER QTY DESCRIPTION REV
0271596 Ref SWING DRIVE INSTALLATION D
1 0100019 AR Compound, Locking
2 0682418 5 Bolt 7/8in- 9NC x 2-1/4in (Grade 8)
3 Ref Swing Motor/Hub Assembly Options (See SWING MOTOR/HUB
ASSEMBLY for Breakdown)
3 3160281 1 Swing Motor/Hub Assembly (Use p/n 1001134098) (Prior to SN
0300074374)
3 3160302 1 Swing Motor/Hub Assembly (Use p/n 1001134098) (Prior to SN
0300074374)
3 3160302 1 Swing Motor/Hub Assembly (Use p/n 1001134098) (SN
0300074374 through 0300152137)
3 1001134098 1 Swing Motor/Hub Assembly (SN 0300152138 to Present)
4 3312002 1 Nut, Jam 5/8in-11NC
5 3900223 1 Screw, Shoulder
6 3952020 1 Setscrew 5/8in-11NC x 2-1/2in
7 4071041 1 Shim
8 4892400 5 Flatwasher 7/8in Hardened
0271512 Ref TURNTABLE BEARING AND LUBE INSTALLATION B
101 0100019 AR Compound, Locking
102 0440251 1 Bearing Kit (Use p/n 2915072) (Kit Includes Bearing and Mounting
Hardware)
103 0682026 40 Bolt 5/8in-11NC x 3-1/4in (Grade 8)
104 0682040 40 Bolt 5/8in-11NC x 5in (Grade 8)
105 2180002 2 Fitting, Grease
106 2180344 2 Fitting, Bulkhead
107 2220063 2 Fitting, Adapter
109 2750528 2 Hose
110 4892000 80 Flatwasher 5/8in, Hardened
0239842 Ref TURNTABLE LOCK INSTALLATION B
202 3421565 1 Pin, Snap
203 1260017 9 in/23cm Chain - #3
204 3760170 2 Ring, Quick Release
205 3421563 1 Pin, Turntable Lock
Ref TURNTABLE WELDMENT OPTIONS:
Ref Machines with ABS Hoods
4620132 Ref Machines with ABS Hoods (Prior to SN 0300080338)
4620149 Ref Machines with ABS Hoods (SN 0300080338 to Present)
4620149 Ref Machines with ABS Hoods with 7500W Generator Prep (SN
0300080338 to Present)
Ref Machines with Steel Hoods
1001107391 Ref Machines with Steel Hoods (Use p/n 1001119911) (Prior to SN
0300149621)
1001119911 Ref Machines with Steel Hoods (SN 0300149621 to Present)
