SECTION 7 - ELECTRICAL
376
1200SJP/1350SJP
3121208
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
110V/50Hz Generator (Note: For Service purchase (1)
p/n 1001109475 & (1) p/n 1001109482.)
812C
See Note
AR
Breaker for Machines with 220V/50Hz Generator (Note:
For Service purchase (1) p/n 1001109477 & (1) p/n
1001109482.)
812C
Ref
Breaker for Machines with 2 Circuit Breakers:
812C
Ref
Breaker for Machines without Latch and Bracket
812C
1001109475
AR
Breaker for Machines without Generator and with
110V/50Hz Generator (16 Amp)
812C
1001109482
1
Breaker for Machines with Latch and Bracket
812C
0861880
1
Box, Breaker
812C
4460956
1
Barrier, Terminal Block End
812C
4460957
1
Block, Terminal
812D
1001101191
1
Connector, Strain Relief
812E
1001097150
1
Connector, Strain Relief
812F
1060908
12 ft/3.6m
Cable, Electrical 12/3
812G
0903484
1
Bracket, AC Receptacle
813
1001111914
1
ClearSky Telematics Harness (Standard on Machines delivered
in North America. Optional on all other machines.)
B
813A
70020808
1
Plug, Male - 23 Position
813A
4460871
5
Socket
813A
4460905
18
Plug, Seal
813B
4460539
2
Plug, Male - 3 Position (Includes Wedge Lock and Seal)
813B
4460944
6
Socket
813B
77363244
2
Wedge Lock
813C
4460945
1
Bulkhead, 3 Way Female
813C
See Note
2
Plug, Male - 3 Position with 120 ohm Resistor (Note: Not
Available For Purchase)
813C
See Note
1
Wedge Lock (Note: Not Available For Purchase)
813D
1001112612
1
Connector, Diagnostic
813D
4460943
2
Pin
813D
4460464
2
Pin
813D
4460466
2
Plug, Seal
813D
1001106736
1
Cap, Dust
813E
1001112796
1
Connector, Diagnostic
813E
4460944
2
Socket
813E
4460466
2
Plug, Seal
814
70002296
1
Harness, Telematics Antenna (Includes Antenna) (Note: No other
parts available)
B
815
1001149818
1
Strobe Light Harness (SN 0300171640 to Present)
A
815A
4460320
1
Connector, Female - 2 Position
815A
4460267
2
Pin, Male
815B
4460897
1
Connector, Female - 2 Position
815B
4460464
2
Pin, Male
Ref
TOOLS (NOT SHOWN)
7002821
1
Crimper (For Wire to Pin/Socket Connections)
7002823
1
Extractor (For Removal of Pin/Socket from Connectors)
4460467
1
Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors)
4460510
1
Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors)
7002828
1
Stripper, Wire
1001137005
1
Cable Kit, Software
