SECTION 1 - FRAME
3121208
1200SJP/1350SJP
59
FIGURE 1-14. TRACTION VALVE ASSEMBLY (SN 0300100131 to Present)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
4641454
Ref
TRACTION VALVE ASSEMBLY
E
1
7012941
3
Cartridge, Solenoid Valve (Steer, Brake and Axle Lockout)
1
7010543
3
Seal Kit - 7012941 Cartridge
1
7012944
2
Coil
2
70000801
1
Cartridge, Valve (Relief)
2
7012998
1
Seal Kit - 70000801 Cartridge
3
70000802
1
Cartridge, Valve (Pilot)
3
7012942
1
Seal Kit - 70000802 Cartridge
4
70000803
1
Pressure Switch
5
70000804
1
Cartridge, Valve (Shuttle)
5
70000805
1
Seal Kit - 70000804 Cartridge
6
70000806
2
Cartridge, Valve (Flow Divider)
6
7017405
2
Seal Kit - 70000806 Cartridge
7
7012955
4
Cartridge, Valve (Check)
7
7012967
4
Seal Kit - 7012955 Cartridge
8
2111012
2
Fitting, Straight
9
2151012
2
Fitting, Elbow
10
2110810
13
Fitting, Straight
11
2110406
3
Fitting, Straight
12
2221086
1
Check, Pressure
13
2220883
1
Plug, #4 (Not Shown)
