SECTION 3 - BOOM
3121208
1200SJP/1350SJP
223
FIGURE 3-1. BOOM INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BOOM INSTALLATION
0271799
Ref
Boom Installation 1200SJP - Without Arctic Package
F
1001138800
Ref
Boom Installation 1200SJP - With Arctic Package
A
0271530
Ref
Boom Installation 1350SJP - Without Arctic Package
F
1001139516
Ref
Boom Installation 1350SJP - With Arctic Package
A
1
0100011
AR
Compound, Locking
2
0100019
AR
Compound, Locking
3
0641608
4
Bolt 3/8in-16NC x 1in
4
0642214
3
Bolt 3/4in-10NC x 1-3/4in
5
Ref
Boom Assembly Options (See BOOM ASSEMBLY for
Breakdown):
5
0801320
1
Boom Assembly 1200SJP - Without Arctic Package
5
1001138801
1
Boom Assembly 1200SJP - With Arctic Package
5
0801315
1
Boom Assembly 1350SJP - Without Arctic Package
5
1001139517
1
Boom Assembly 1350SJP - With Arctic Package
6
1684162
2
Lift Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
7
3340927
1
Pad
8
Ref
Pin, Load Sensing Options:
8
3422933
1
Pin, Load Sensing (Prior to SN 0300080450)
8
3423194
1
Pin, Load Sensing (SN 0300080450 through 0300086185)
8
3423208
1
Pin, Load Sensing (SN 0300086186 to Present)
9
3422955
1
Pin
10
3841287
2
Keeper, Pin
11
4751600
4
Flatwasher 3/8in Regular
12
3520110
1
Plug (Prior to SN 0300080450)
13
3841581
1
Keeper, Pin
14
3422988
1
Pin
