SECTION 7 - ELECTRICAL
320 1200SJP/1350SJP 3121208
FIGURE 7-1. ELECTRICAL DIAGRAM LIST
ITEM PART NUMBER QTY DESCRIPTION REV
Ref Note: Diagrams not shown are available from the JLG Service
Department.
4933262 Ref CHASSIS ILLUMINATION LIGHTS ELECTRICAL DIAGRAM
1001102417 Ref CLEAR SKY TELEMATICS ELECTRICAL SCHEMATICS
0272066 Ref COLD WEATHER KIT WITH ETHER WIRING DIAGRAM
0272068 Ref COLD WEATHER KIT WITH ETHER WIRING DIAGRAM
Ref GENERATOR ELECTRICAL DIAGRAM
Ref Note: For Module Identification, refer to Revision Log page A.
Ref Without UGM
Ref 2500W Generators
4933215 Ref ANSI Spec (110Volt)
Ref CE Spec
4933215 Ref 110Volt (Prior to SN 0300080338)
4933300 Ref 110Volt (SN 0300080338 to Present)
4933216 Ref 220Volt (Prior to SN 0300129806)
1001100027 Ref 220Volt (SN 0300129806 to Present)
4933216 Ref Australian Spec (220Volt Only) (Prior to SN 0300129806)
Ref 7500W Generators
4933267 Ref Hydraulic Driven Generator (Prior to SN 0300080338)
4933264 Ref Belt Driven Generator (SN 0300080338 to Present)
Ref With UGM
Ref 2500W Generators
1001120381 Ref Caterpillar/Deutz Engine - 110/220Volt - 60Hz
1001120382 Ref Deutz Engine - 110/220Volt - 50Hz
Ref 4000W Generators
1001153257 Ref Deutz Engine – 60Hz (ANSI Export / CE / Japanese Spec)
1001162901 Ref Deutz Engine – 50Hz (ANSI Export / CE / Japanese Spec)
1001162899 Ref Deutz Engine – 50Hz (Australian Spec)
1001162900 Ref Deutz Engine –50Hz (CE Spec)
Ref 7500W Generators
1001122528 Ref Caterpillar/Deutz Engine (Prior to SN 0300182753)
1001157770 Ref Caterpillar, Deutz TD2011 Engine and Deutz TCD2.9L4
Engines Machines (SN 0300182753 to Present)
Ref GROUND CONTROL BOX ELECTRICAL DIAGRAM
Ref Note: For Module Identification, refer to Revision Log page A.
Ref Without UGM
4933268 Ref Ground Control Box Electrical (Prior to SN 0300087579)
4933340 Ref Ground Control Box Electrical (SN 0300087579 through
0300098919)
4933389 Ref Ground Control Box Electrical (SN 0300098920 to Present)
1001116206 Ref With UGM
4933253 Ref HEADLIGHT AND TAILIGHTS ELECTRICAL DIAGRAM
4933249 Ref PLATFORM FLOODLIGHTS ELECTRICAL DIAGRAM
0272096 Ref PLATFORM WORKLIGHTS ELECTRICAL DIAGRAM
0272097 Ref PLATFORM WORKLIGHTS ELECTRICAL DIAGRAM
Ref STANDARD ELECTRICAL SCHEMATIC OPTIONS:
Ref Note: For Module Identification, refer to Revision Log page A.
Ref Without UGM
1870149 Ref Standard Electrical Schematic (Prior to SN 0300087579)
