JLG 1350SJP Parts Manual User Manual
Page 253
SECTION 4 - PLATFORM
3121208
1200SJP/1350SJP
253
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
104A
4360031
1
Footswitch (Prior to SN 0300143790)
104A
7000625
2
Block, Contact (4360031 Footswitch)
104A
1001117320
1
Footswitch (SN 0300143790 through 0300167891)
104A
70003483
1
Block, Contact (1001117320 Footswitch)
104A
1001117172
1
Footswitch (SN 0300167892 to Present)
104A
70002902
1
Switch, 20Amp
104A
70002903
1
Gasket
104A
70002904
4
Replacement Kit, Bolt
104A
70002905
1
Cover, Aluminum
104B
1060918
7 ft/2.14m
Cable, Electrical - 18/3
104C
4460071
1
Connector, Strain Relief
105
3311405
7
Locknut 1/4in-20NC
106
3311605
4
Locknut 3/8in-16NC
107
3380434
1
Panel, Molded
108
4740362
7
Washer, Fender
109
4751400
4
Flatwasher 1/4in Regular
110
4751600
8
Flatwasher 3/8in Regular
Ref
TRAY INSTALLATIONS (OPTIONAL)
201
1580012
1
Tray, Storage (Center)
202
1580013
1
Tray, Storage (Rail Mounted - Not Shown)
Ref
WORKLIGHTS INSTALLATION (optional)
0272097
Ref
Worklights Installation 1200SJP
E
0272096
Ref
Worklights Installation 1350SJP
E
301
Ref
Fastener Options:
301
0641414
4
Fastener (Prior to SN 0300112484)
301
2080040
4
Fastener (SN 0300112484 to Present)
304
2920140
2
Worklight
304
7016399
2
Bulb, Replacement (1 Per Light)
306
3311405
4
Locknut 1/4in-20NC (Prior to SN 0300112484)
307
3536089
2
Plate, Lamp Mounting
314
4711400
8
Flatwasher 1/4in Thin (Prior to SN 0300112484)
Ref
FLOODLIGHTS INSTALLATION (OPTIONAL)
0272093
Ref
Floodlights Installation 1200SJP
B
0272092
Ref
Floodlights Installation 1350SJP
B
401
0641518
2
Bolt 5/16in-18NC x 2-1/4in
402
2560173
2
Handle, Star Knob
403
2920157
2
Floodlight
403
7024452
2
Bulb, Replacement (1 Per Light)
404
3250585
1
Nameplate - Lights On
405
4060802
1
Guard, Switch
406
4360336
1
Switch, Toggle
407
4420037
AR
Tape, Insulation (Not Shown)
408
4751800
2
Flatwasher 1/2in Regular
409
4846561
1
Mount, Light
411
1060708
Ref
Cable, Electrical 10/3 (Not Shown)
411
1060708
144
ft/44m
Cable, Electrical 10/3 1200SJP
411
1060708
150
ft/46m
Cable, Electrical 10/3 1350SJP
