SECTION 6 - HYDRAULIC
3121208
1200SJP/1350SJP
303
FIGURE 6-2. HYDRAULIC DIAGRAM - OSCILLATING AXLE
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
HYDRAULIC DIAGRAM - OSCILLATING AXLES
1283457
Ref
Hydraulic Diagram for Caterpillar Engine Machines with
Rexroth Pumps
G
1283457
Ref
Hydraulic Diagram for Deutz BF4M2011 & TD2011 Engine
Machines with Rexroth Pumps
G
1001152971
Ref
Hydraulic Diagram for Deutz TCD2.9L4 Engine Machines with
Rexroth Pumps
A
2792647
Ref
All Machines
4
1001118859
Ref
Hydraulic Diagram for Machines with Sauer Pumps
C
2792647
Ref
All Machines
4
1
2110406
2
Fitting, Straight
2
2110604
1
Fitting, Straight
3
2110606
2
Fitting, Straight
4
2170504
1
Fitting, Tee
5
2170506
1
Fitting, Tee
6
2753726
1
Hose
7
2753719
2
Hose
8
2753727
1
Hose
9
2753729
2
Hose
2902480
1
Kit, Hose (Includes Items 6-9) (SN 0300089069 through
0300096239)
