SECTION 7 - ELECTRICAL
362 1200SJP/1350SJP 3121208
FIGURE 7-4. HARNESS COMPONENTS INSTALLATION (WITH UGM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref NOTE: FOR MODULE IDENTIFICATION, REFER TO REVISION
LOG PAGE A.
Ref HARNESS COMPONENTS INSTALLATION
Ref PLATFORM CONSOLE BOX COMPONENTS
0861631 Ref Platform Console Box Components (Use p/n 1001146161)
(SN 0300079596 through 0300171348) L
1001146161 Ref Platform Console Box Components (SN 0300171349 to
Present) B
1 0100048 AR Grease, Dielectric
4 Ref Footswitch Components:
4A 1060918 7 ft/2.14m Cable, Electrical - 18/3
4B 4460071 1 Connector, Strain Relief
4C 4460226 2 Socket, Female
4C 4460464 1 Pin, Male
46 4460428 4 Connector, Strain Relief
47 4460470 1 Nut, Terminal
48 4460471 1 Lockwasher, Terminal
50 4460496 1 Lockwasher, Terminal
51 4460497 1 Nut, Terminal
52 4460708 2 Receptacle, Female - 15 Position
53 4460905 5 Seal, Plug
58 4922666 1 Harness, Analyzer Cable 2-B
58 4460226 4 Socket, Female (Not Shown - Located at J2)
58A 4460761 1 Connector, Female - 4 Position
58A 4460227 4 Pin, Male
59 4923448 1 Harness, Platform Box (See Items 101-111 for Breakdown)
4923448 Ref PLATFORM BOX HARNESS ASSEMBLY 3-B
101 4460866 1 Connector - 19 Pin
101 4460464 7 Pin, Male Deutsch 16 Ga
101 4460508 4 Pin, Male Deutsch 12 Ga
101 4460943 3 Pin, Male 16 Ga (Gold Plated)
102 4460874 1 Connector - 35 Position (Natural)
102 4460871 7 Socket, Female
102 4460905 4 Plug
103 4460876 1 Connector - 35 Position (Blue)
103 4460871 32 Socket, Female
103 4460905 3 Plug
104 4460873 1 Connector - 35 Position (Black)
104 4460871 34 Socket, Female
104 4460905 1 Plug
105 4460879 1 Connector, Male - 2 Position
105 4460887 2 Terminal (12 Gauge)
106 4460418 12 Connector, Female - 6 Position
106 4460419 36 Socket, Female
107 4460225 5 Plug, Male - 6 Position
107 4460226 21 Terminal (16 Gauge)
108 4460225 1 Plug, Male - 6 Position
108 4460227 5 Pin, Male
109 4460434 2 Plug, Male - 15 Position
109 4460227 14 Pin, Male
