SECTION 4 - PLATFORM
3121208 1200SJP/1350SJP 277
FIGURE 4-8. SOFT TOUCH SYSTEM INSTALLATION (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref SOFT TOUCH SYSTEM INSTALLATIONS OPTIONS:
0273824 Ref 6ft/1.8m Platforms B
0272427 Ref 8ft/2.4m Platforms E
0273706 Ref 8ft/2.4m Platforms w/Fall Arrest B
1 0100011 AR Compound, Locking
2 0200048 2 Arm, Switch Activator
3 0630462 8 Bolt, Carriage
4 0641414 8 Bolt 1/4in-20NC x 1-3/4in
5 0721005 4 Screw, Machine #10-24 x 5/8in
6 Ref Bumper Kit Options:
6 0940134 1 6ft/1.8m Platforms
6 0940103 1 8ft/2.4m Platforms
6 0940133 1 8ft/2.4m Platforms w/Fall Arrest
8 1060903 4 Wire Rope and Eyebolt Assembly
10 3311401 8 Nut 1/4in-20NC
11 3311501 8 Nut 5/16in-18NC
12 Ref Plate, Striker Options:
12 3575359 2 6ft/1.8m Platforms
12 3574091 2 8ft/2.4m Platforms
13 4240099 7 Tie-Strap (Not Shown)
14 4360057 2 Switch, Limit
16 4420068 1 Tape, Yellow Adhesive
17 4460049 2 Connector, Strain Relief
18 4460234 7 Base, Tie-Strap Mounting (Not Shown)
20 4751400 8 Flatwasher 1/4in Regular
21 4751500 12 Flatwasher 5/16in Regular
22 4751800 8 Flatwasher 1/2in Regular
23 Ref Rail, Soft-Touch Options:
23 3841589 1 6ft/1.8m Platforms
23 4846673 1 8ft/2.4m Platforms
0272444 Ref SOFT TOUCH COUNTERWEIGHT INSTALLATION (NOT
SHOWN) C
4821397 1 Counterweight (Located in Frame)
