SECTION 2 - TURNTABLE
3121208
1200SJP/1350SJP
161
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
212
4751000
4
Flatwasher #10 Regular
213
4751600
2
Flatwasher 3/8in Regular
217
3311605
2
Locknut 3/8in-16NC
218
0100035
AR
Compound, Locking
0271808
Ref
ILLUMINATION LIGHTS INSTALLATION (OPTIONAL)
B
301
0100011
AR
Compound, Locking
302
0641610
2
Bolt 3/8in-16NC x 1-1/4in
303
0642612
2
Bolt 1in-8NC x 1-1/2in
304
0902206
2
Bracket, Mounting
305
2920157
4
Headlight
305
7024452
4
Bulb, Replacement (1 Per Light)
306
3573336
2
Plate, Mounting
307
3740080
1
Relay, Bosch
308
4220162
2
Spacer
309
4751600
2
Flatwasher 3/8in Regular
0271874
Ref
PINION SHIELD INSTALLATION
A
401
0100011
AR
Compound, Locking
402
0641608
4
Bolt 3/8in-16NC x 1in
403
3573355
1
Plate, Pinion
404
4751600
4
Flatwasher 3/8in Regular
1001111219
Ref
SHIELDS INSTALLATION (OPTIONAL)
G
502
0641506
5
Bolt 5/16in-18NC x 3/4in
503
0641606
2
Bolt 3/8in-16NC x 3/4in
504
0641608
3
Bolt 3/8in-16NC x 1in
506
2940045
1
Latch, Paddle
508
3311605
AR
Locknut 3/8in-16NC
510
4711500
7
Flatwasher 5/16in Thin
511
4751600
AR
Flatwasher 3/8in Regular
513
1001111175
1
Plate, Bearing Cover
514
1001111176
1
Plate, Bearing Cover
515
1001112911
1
Plate, Striker
516
1001111193
1
Door
517
1001113173
1
Decal - Emergency Stop
518
1001114392
1
Plug, Rubber
519
1001115168
1
Shim (SN 0300138349 to Present)
520
0100011
AR
Compound, Locking
521
0630511
1
Bolt 3/8in-16NC x 2in
522
0641404
1
Bolt 1/4in-20NC x 1/2in
523
0791604
2
Bolt 3/8in-16NC x 1/2in
524
4751400
1
Flatwasher 1/4in Regular
525
1001115440
1
Shield, Turntable
