SECTION 4 - PLATFORM
3121208 1200SJP/1350SJP 255
FIGURE 4-2. PLATFORM COMPONENTS INSTALLATION (FALL ARREST PLATFORM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref PLATFORM ASSEMBLY (FALL ARREST) (OPTIONAL)
3510884 Ref 6ft (1.83m) ANSI and ANSI Export Spec E
3510868 Ref 8ft (2.44m) ANSI Spec (Prior to SN 0300186186) F
1001144596 Ref 8ft (2.44m) ANSI Spec (SN 0300186186 to Present) D
3510877 Ref 8ft (2.44m) Australian and CE Specs (Prior to SN 0300186186) D
1001175535 Ref 8ft (2.44m) Australian and CE Specs (SN 0300186186 to
Present) A
Ref Note: Replacement Decals Must be Ordered Separately - See
DECALS SECTION.
Ref Note: Aftermarket installation requires additional
counterweight - See SPECIAL OPTIONS SECTION.
1 0681814 2 Bolt 1/2in-13NC x 1-3/4in
2 0681822 6 Bolt 1/2in-13NC x 2-3/4in
3 0962270 2 Bearing, Oilite
4 1702773 1 Decal - JLG
5 Ref Decal - Safety Options:
5 1705014 1 ANSI and ANSI Export Spec
5 1706501 1 Australian and CE Specs
6 2410014 1 Gate Weldment
7 3271805 AR Locknut 1/2in-13NC
8 3311605 1 Locknut 3/8in-16NC
9 See Note 1 Platform Weldment (Note: Not Available - Purchase Platform
Assembly)
10 3520072 1 Cap-Plug
11 Ref Cable, Fall Arrest Options:
11 1060919 1 6ft (1.83m) Platform
11 3890040 1 8ft (2.44m) Platform
12 3900054 1 Bolt 1/2in-13NC x 1-3/4in
13 4711800 2 Flatwasher 1/2in Thin
14 4751800 AR Flatwasher 1/2in Regular
15 Ref Decal - Drop Bar Options: (SN 0300085906 to Present)
15 1706385 1 ANSI and ANSI Export Spec
15 1706493 1 Australian and CE Specs
