SECTION 5 - CYLINDER
3121208
1200SJP/1350SJP
281
FIGURE 5-1. AXLE EXTENSION CYLINDER ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1684102
Ref
AXLE EXTENSION CYLINDER ASSEMBLY
D
1
0100011
AR
Compound, Locking
2
0100038
AR
Primer, Locking
3
0100063
AR
Loctite #RC 609
4
0630535
3
Capscrew 1/4in-20NC x 1-1/8in
5
0961896
1
Bushing, Tapered
6
1683056
1
Head
7
1684103
1
Barrel Weldment
8
1684105
1
Rod Weldment
9
3480272
1
Piston
11
2901773
2
Ring, Wear
12
2901773
1
Ring, Back-Up
13
2901773
2
Ring, Back-Up
14
2901773
1
O-Ring
15
2901773
1
O-Ring
16
2901773
1
Wiper, Rod
17
2901773
1
Seal
18
2901773
2
Ring, Wear
19
2901773
1
T-Seal
20
3760369
1
Ring, Washer
21
3931620
8
Bolt 3/8in-16NC x 1-1/4in
22
4640509
2
Cartridge, Holding Valve
22
2900792
2
Seal Kit - 4640509 Cartridge Valve (1 Per Valve)
23
2220883
2
Plug, O-Ring
51
2901773
1
Seal Kit (Includes Items 11-19)
