SECTION 5 - CYLINDER
3121208
1200SJP/1350SJP
291
FIGURE 5-6. STEER CYLINDER ASSEMBLY (Prior to SN 0300073367)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Note: Original Equipment Cylinder may have been replaced
with Service Replacement p/n 1684412 - See STEER
CYLINDER ASSEMBLY. Identify p/n stamped on cylinder
before ordering parts.
1684034
Ref
STEER CYLINDER (Prior to SN 0300073367)
A
1
7024415
1
Barrel
2
7024416
1
Rod
3
7024417
1
Head
4
7024418
1
Piston
5
7024419
1
Nut
6
0100006
AR
Compound, Locking
8
0961950
2
Bushing (Rod End)
9
0961949
2
Bushing (Barrel End)
11
7024420
1
Wiper
12
7024420
1
Seal, Rod
13
7024420
1
Ring, Wear
14
7024420
1
Seal, Piston
15
7024420
1
Ring, Wear
16
7024420
1
O-Ring
17
7024420
1
Ring, Back-up
18
7024420
1
O-Ring
51
7024420
1
Seal Kit (Includes Items 11-18)
